| 型号 | 导线截面(mm2) | 导体结构(mm2) | 产品直径(mm) | 70℃绝缘电阻器(MΩ·KM) | 20℃导体直流电阻器(Ω/KM) |
|---|---|---|---|---|---|
| TVVBP | 36X0.75+(2X2P)X0.75 | 30/0.18 | 62.0X9.8 | ≥0.011 | ≤26.0 |
| TVVBP | 36X0.75+(2X2P)X0.75+TV(STV75-4) | 30/0.18 | 61.5X9.0 | ≥0.011 | ≤26.0 |
| TVVBP | 40X0.75+(2X2P)X0.75 | 30/0.18 | 61.5X9.0 | ≥0.011 | ≤26.0 |
| TVVBP | 48X0.75+(2X2P)X0.75 | 30/0.18 | 68.5X10.0 | ≥0.011 | ≤26.0 |
| TVVBP | 30X0.75+(2X2P)X0.75 | 30/0.18 | 52.5X9.0 | ≥0.011 | ≤26.0 |
| TVVBP | 20X0.75+(2X2P)X0.75 | 30/0.18 | 44.2X9.1 | ≥0.011 | ≤26.0 |
| TVVBP | 24X0.75+(2X2P)X0.75 | 30/0.18 | 42.5X9.0 | ≥0.011 | ≤26.0 |
| TVVBP | 48X0.75+(2X2P)X0.75 | 30/0.18 | 68.5X9.5 | ≥0.011 | ≤26.0 |
| TVVBPG | 36X0.75+(2X2P)X0.75 | 30/0.18 | 63.0X9.2 | ≥0.011 | ≤26.0 |
| TVVBPG | 36X0.75+(2X2P)X0.75+TV(SYV75-4) | 30/0.18 | 72.5X9.9 | ≥0.011 | ≤26.0 |
| TVVBPG | 42X0.75+(2X2P)X0.75 | 30/0.18 | 75.0X9.8 | ≥0.011 | ≤26.0 |
| TVVBPG | 48X0.75+(2X2P)X0.75 | 30/0.18 | 80.0X9.5 | ≥0.011 | ≤26.0 |
| TVVBPG | 20X0.75+(2X2P)X0.75 | 30/0.18 | 51.0X8.9 | ≥0.011 | ≤26.0 |
| TVVBPG | 24X0.75+(2X2P)X0.75 | 30/0.18 | 64.0X10.2 | ≥0.011 | ≤26.0 |
| TVVBPG | 30X0.75+(2X2P)X0.75 | 30/0.18 | 58.0X8.2 | ≥0.011 | ≤26.0 |
| TVVBPG | 40X0.75+(2X2P)X0.75 | 30/0.18 | 74.0X9.0 | ≥0.011 | ≤26.0 |
